shown in Fig.356. This machine maintains a constant currentin its circuit, notwithstanding changes in its ex-ternal circuit. Machine, Dynamo-Electric, Shunt-Wound A dynamo-electric machine in which the field magnet coils are placed in a shunt-to the armature circuit, so that only aportion of the… … D D D DFig. 357. Shunt Dynamo. In a shunt dynamo-electric machine, an in-crease in the resistance of the external circuit in-creases the electromotive force, and a decrease inthe resistance of the external circuit decreases theelectromotive force. This is just the reverse ofthe series-wound dynamo.…
