sistance. Box, Resistance.) There are two general forms of WheatstonesBridge, the box form, and the sliding form. Bridge, Electric, Arms of The resistances of an electric bridge or balance.(See Bridge, Electric?) Bridge, Electric, Box Form of A commercial form of bridge or balance inwhich all the… … Fig. 74. Box Balance. perspective in Fig. 74, and in plan in Fig. 75.The bridge arms, corresponding to the resistances x 1000 100 10 9 10 100 1000
