ent. The unknown resistance is then inserted in thegap at Q, and a known resistance, generally theresistance box, in that at R. The galvanometerhas one of its terminals connected to the metalstrip between Q and R, and its other terminal tothe sliding key. The battery terminals are con-nected to the… … Fig. yg. Slide Form of Bridge. in length, so arranged that only one wire, or twoin series, or all three in series, can be used. Mat-ters being now arranged as shown, the slidingkey is moved until no current passes through thegalvanometer when the key is depressed. The slide form of bridge is not…
