A dictionary of electrical words, terms and phrases (1896)
Houston, Edwin J. (Edwin James), 1847-1914 · New York, The W.J. Johnston company · leaf 125
mature, that is, in an arm-ature the coils of which are connected in a closed,circuit, the collecting brushes rest on the commu-tator cylinder at the neutral line, or on the diame-ter of commutation. In an open-circuited armature, however, wherethe coils are independent of each other, thecollecting… … Fig. JJ4» Diameter of Commutation. term, the diameter of coni77iutation is that diameteron the commutator which joins the points of con-tact of the collecting brushes. The neutral linenn, Fig. 154, it will be noticeddoes not occupy a vertical position, but is dis-placed somewhat in the direction of…
