A dictionary of electrical words, terms and phrases (1896)
Houston, Edwin J. (Edwin James), 1847-1914 · New York, The W.J. Johnston company · leaf 71
Resistance Coils, thick pieces of brass, E, E, E, Fig. 76. On the in-sertion of the plug-keys, at S, S, the coils are cut-out by short-circuiting. Care should be taken tosee that the plug-keys are firmly inserted and freefrom grease or dirt, as otherwise the coil will not becompletely cut out. As… … z« e Fig. 7 7. Electric Bala nee. the unknown resistance between z and r; the bat-tery is connected tox and z. A convenient pro-portion being taken for the value of the propor-tional coils, resistances are inserted in the arm C,until no deflection is shown by the galvanometerG. The similarity…
Electricity · Electrical engineering
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
