Dressings and finishings for textile fabrics and their application; description of all the materials used in dressing textiles (1911)

Polleyn, Friedrich, Salter, Charles · London, Scott, Greenwood · leaf 251

An illustration from Dressings and finishings for textile fabrics and their application; description of all the materials used in dressing textiles, 1911, leaf 251 — ch pusses from a belt pulley on the axis of the lowersqueezing roller, to the belt pulley, A, of the folder shaft, F, overthe guide rollers, s, s, on the arm, r. The crank shaft, e, receivesmotion through the pulley, Y. The folder shafts, a, b, have a quickinward motion, to prevent the cloth from… … rinsing, and blueing, as well as starching. For heavy finish, so that the dressing is forced into the threads from both sides of the goods, 234 DRESSINGS FOR TEXTILE FABRICS the latter are passed from (/ over the guide rollers, i, into thewooden starch trough, thence by the rollers, r4, r5, between…

Textile finishing
