The Driggs-Schroeder system of rapid-fire guns; guns, mounts, ammunition (1896)

American Ordnance Company · [Baltimore, Deutsch lithographing & printing company] · leaf 116

An illustration from The Driggs-Schroeder system of rapid-fire guns; guns, mounts, ammunition, 1896, leaf 116 — PLATE XV. 6-POUNDER SHELL, 4-INCH PLATE. 2. 3-POUNDER SHELL, 3-INCH PLATE. 3. 1-PO' PROJECTILES AFTER PERFORATION OF IRON

Ordnance, Rapid-fire

Internet Archive · Smithsonian Libraries · Public domain (published before 1931). Free to use for anything.
