Dynamo electric machinery; its design, construction, and operation; direct-current machines (1915)
Sheldon, Samuel, 1862-1920, Hausmann, Erich, 1886- joint author · New York, D. Van Nostrand Company; · leaf 187
K. W., i6-pole, 100 rev. permin. General Electric Company direct-connected engine-driven railway generator. These generators are built insizes from 100 K. W. to 2700 K. W., and are designed toyield the prevailing full-load railway voltages of 550, 575,or 600 volts. The field-magnet yoke is of cast… … Fig. loi. bolted to the frame, and may be removed laterally withouttaking out the armature. Commutating poles are providedin most sizes, to compensate for armature reaction, thus in- 1/6 DYNAMO ELECTRIC MACHINERY. suring good commutation at all loads. The armature spideris equipped with vanes which…
Electric machinery
