as a portion of the unbalanced load-cur-rent of the branch to which it is directly connected. Thelast will flow in a direction opposite to that indicated in thefigure. According to the foregoing discussion, (6) and (7)^the apportioning is as follows : — A = /„ + (4 - ■ 1)7.1 + BIb + CIc. and /, =… … Fig. 181. The equations of (9) and (10) can be extended to embraceany number of branches. Balancers having three elements,however, satisfactorily meet the requirements of multiple- BOOSTERS. 279 voltage systems for speed control of motors. Commonbranch pressures are 40, 80, and 120 volts…
