maximum scaledeflection. The appearanceof switchboard voltmetersand ammeters is shown inFig. 201. F^s- 20I- Another type of volt- meter, depending for its operation on the attraction betweentwo electrically charged bodies, is the electrostatic volt-meter. Low-voltage instruments of this type… … CJtNTRAL-STATION EQUIPMENT. 309 resistance is connected in series with the instruments, suchresistances being known as mtdtipliers. If R be the resist-ance of a low-reading voltmeter, and r be that of the multi-plier, then the range of the instrument has been increasedr+ R R times. Multipliers…
