Fig. 55. Fig. 56. cuit. Figure 55 shows a complete core-type transformer of theGeneral Electric Company without its containing case, and Fig.56 is a sectional view of the same transformer in its containing THE DYNAMO AND THE TRANSFORMER. 69 case. The four terminals of the coarse wire windings are…
