complete core-type transformer of theGeneral Electric Company without its containing case, and Fig.56 is a sectional view of the same transformer in its containing THE DYNAMO AND THE TRANSFORMER. 69 case. The four terminals of the coarse wire windings are broughtout through the case, and tlie four… … Fig. 57. The shell-type trmisformer. — A transformer in which the coilsform an elongated structure like Fig. 54 and are surrounded bylaminated iron, is called a shell-type transformer. Figure 57shows the assembled windings of a shell-type transformer of theAllis-Chalmers Company, and Fig. 58 shows…
