Early renaissance architecture in England; a historical & descriptive account of the Tudor, Elizabethan & Jacobean periods, 1500-1625, for the use of students and others (1901)
Gotch, J. Alfred (John Alfred), 1852-1942 · London, B. T. Batsford · leaf 454
:3c—An Un-named Elevation, the garden SYDE, LODGINGS BELOW AND GALLERYABOVE. J. T. (PAGE I08). the same accurate symmetry.The garden syde, lodgings R 2 250 EXERCISES IN INGENUITY OF PLANNING. below and gallery above. J. T., and as it is initialed by Thorpe,it helps to identify as his many of the… … 231.—An Un-named Plan (pages 145, 146). 1. Entrance. 6. Buttery. 2. Hall (Kitchen below). 7. Woodyard. 3. Parlour. 8. Closet. 4. Lodging Chamber. 9. Stairs. 5. Inner Chamber. 10. Open Space. 11. Terrace. terrace. The angles formed where the three rooms join areoccupied by three towers, one of which…
Architecture, Renaissance · Architecture
Internet Archive · Getty Research Institute · Public Domain Mark 1.0. Free to use for anything.
