Easy steps in architecture and architectural drawing .. (1915)
Hodgson, Frederick Thomas, 1836- [from old catalog] · Chicago, Ill., Printed by F. J. Drake & co. · leaf 113
6 10 Fig. 21. SECTION OP GRANITE BLOCK ROOFED CHAMBER INTHE PYRAMID OF CHEOPS. but for the most part very considerable. The largest isone of those at Ghizeh, and has a perpendicular heightof 448 ft. and a breadth of 728 ft. on each side of thebase. 106 EASY LESSONS IN ARCHITECTURE In an esthetic… … Pig. 22. TEMPLE OF EDFU. A.—Pylon. B—Obelisks. C—Entrance. D—Temple-Court. E—Porti- cus. F—Pronaos (Court with colonnades). G—Noas. H—Sanctuarium. as to the associations which fancy may link with them. 26. The principal elements in the designs of the Temples (Fig. 22) consist, firstly, of the…
Architecture · Architectural drawing
