Easy steps in architecture and architectural drawing .. (1915)
Hodgson, Frederick Thomas, 1836- [from old catalog] · Chicago, Ill., Printed by F. J. Drake & co. · leaf 117
rs (seeFig. 22 D) with rows of columns (E) either at the twoside walls, or on all the four sides; or sometimes onlyon three. On these columns rest cross-pieces of stone,which form an architrave and support the roof-slabs ofthe area. They thus form a kind of entablature, which,as in the case of the… … Fig. 27. CORNICE ENTABLATURE AT THE GREAT TEMPLE ATPHILAE. 28. Passing through the colonnade the temple (Fig.28) is reached; in no instance at once the inner sanctu-ary, but other initiatory spaces, which invariably occur:and, firstly, an entrance-hall, the polystyle hall (Fig.22 F) is entered, the…
Architecture · Architectural drawing
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
