sting offive domes. The cross is formed by the intersectionof the nave and transept and a dome is raised on piers 184 EASY LESSONS IN ARCHITECTURE at the point of intersection, whilst over the extremityof each arm of the cross is a similar dome, only with-out windows. (Fig. 94.) The arms of the… … Fig. SECTION OF THE CHURCH AT THE THEOTOKOSAT CONSTANTINOPLE. But the ground-plan of a square with the centraldome resting on piers or columns, and with four smallerdomes at the corners, is more common and more charac-teristic of the Byzantine style. The womens galleries EAST LESSONS IN…
