Easy steps in architecture and architectural drawing .. (1915)
Hodgson, Frederick Thomas, 1836- [from old catalog] · Chicago, Ill., Printed by F. J. Drake & co. · leaf 41
he arch rightly constructed, with a doubleor treble course of bricks to form the arch, it will, afterthe wall has been carried up a little way, be capableof supporting as much weight as if there were no open-ing. 34 EASY LESSONS IN ARCHITECTURE GENERAL DETAIL OF MEDIAEVAL ARCHITECTURE. Section… … Fig. 22. TARRAGONA CATHEDRAL. Q. How many different kinds of arches are there,and name them?A. Nine, viz.: 1. Semi-circular, used in the Roman, Saxon and Nor- man styles, but rarely met with in the Gothic. 2. The lancet or sharp-pointed, belonging to the Early English period. EASY LESSONS IN…
Architecture · Architectural drawing
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
