Easy steps in architecture and architectural drawing .. (1915)
Hodgson, Frederick Thomas, 1836- [from old catalog] · Chicago, Ill., Printed by F. J. Drake & co. · leaf 480
of the wood every time the lead is slightly worn.Fig. 88 shows the T-square and pencil withthe two hands in position for drawing anordinary horizontal line. The pencil should beupright when looking in the lengthways directionof the line, and sloping about five degrees fromthe upright in the…
Architecture · Architectural drawing
