Easy steps in architecture and architectural drawing .. (1915)
Hodgson, Frederick Thomas, 1836- [from old catalog] · Chicago, Ill., Printed by F. J. Drake & co. · leaf 483
cale in order to show the 96 ARCHITECTURAL DRAWING SELF TAUGHT PLATE 6. This plate shows the draftsman how to preparedetails so that they may be followed by the actualworkman. This shows some details of theporch, giving the construction of cornice andother work. This is shown here to a scale of one… … \r ARCHITECTURAL DRAWING SELF TAUGHT 97
Architecture · Architectural drawing
