Easy steps in architecture and architectural drawing .. (1915)
Hodgson, Frederick Thomas, 1836- [from old catalog] · Chicago, Ill., Printed by F. J. Drake & co. · leaf 550
in doorways,windows, and fireplaces of buildings, and theintrados are generally supported by a bar of ARCHITECTURAL DRAWING SELF TAUGHT 149 iron or beam of wood. In some very ancientexamples the voussoirs are cut to a peculiarform, with the idea of securing great stabilityand strength, as shown at… … gather from them all he will immediately requireto know, and after a thorough mastery of theseexamples he will have no difficulty in obtaininga higher knowledge from the thousand and oneother sources that are available, should he sodesire. SOME MISCELLANEOUS PRACTICE Suppose it is necessary to show…
Architecture · Architectural drawing
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
