Easy steps in architecture and architectural drawing .. (1915)
Hodgson, Frederick Thomas, 1836- [from old catalog] · Chicago, Ill., Printed by F. J. Drake & co. · leaf 551
ediately requireto know, and after a thorough mastery of theseexamples he will have no difficulty in obtaininga higher knowledge from the thousand and oneother sources that are available, should he sodesire. SOME MISCELLANEOUS PRACTICE Suppose it is necessary to show a door andcasings in abrick… … Fig. 149. Style of door, and finish, and work to scaleaccordingly. In this case I show an elevation,Fig. 151, and plan respectively with a four paneled door with jamb and soffit lining.Fig. 150 shows a por-tion of the plan en-larged. In this case it willbe seen that the dooris hung to the…
Architecture · Architectural drawing
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
