Easy steps in architecture and architectural drawing .. (1915)
Hodgson, Frederick Thomas, 1836- [from old catalog] · Chicago, Ill., Printed by F. J. Drake & co. · leaf 571
Fig. 174. each other, the distances being shown at i h g. Another illustration of a square being set diagonally is shown at Fig. 174, which illustrates ARCHITECTURAL DRAWING SELF TAUGHT 167 an open balustrade in Gothic style. The studentshould have no difficutly whatever in laying thisdiagram off,…
Architecture · Architectural drawing
