Easy steps in architecture and architectural drawing .. (1915)
Hodgson, Frederick Thomas, 1836- [from old catalog] · Chicago, Ill., Printed by F. J. Drake & co. · leaf 575
again by the introduction of small circles at thejunction of the lines, as shown in one instance.This may again be elaborated by adding a lineor dot to the circle as shown. Another example formed of squares and half 17C ARCHITECTURAL DRAWING SELF TAUGHT squares Is shown in Fig. i8i. This…
Architecture · Architectural drawing
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
