Easy steps in architecture and architectural drawing .. (1915)
Hodgson, Frederick Thomas, 1836- [from old catalog] · Chicago, Ill., Printed by F. J. Drake & co. · leaf 610
Fig. 219. sufficient to give the student a good insight intoGothic tracery work, but it must be rememberedthat in Gothic work the designs of this characterare innumerable. Portions of these designs are ARCHITECTURAL DRAWING SELF TAUGHT 197 used in window and door heads, and in ahundred other… … Fig. 220. foundation of the whole of the work. All theother ornamentation seems to cluster aroundthe three larger circles; this is the peculiarityof these two examples, but it must be borne in 198 ARCHITECTURAL DRAWING SELF TAUGHT mind that the trefoil is not the only basis aroundwhich the old…
Architecture · Architectural drawing
