Easy steps in architecture and architectural drawing .. (1915)
Hodgson, Frederick Thomas, 1836- [from old catalog] · Chicago, Ill., Printed by F. J. Drake & co. · leaf 633
Fig. 232. the leading curves thus described as shown inthe drawing. The skeleton shown in the illustration, Fig.232, exhibits an ornament drawn altogether withthe compass. The centers are all shown andlettered for reference; r being the general 216 ARCHITECTURAL DRAWING SELF TAUGHT … center, while a,j, d, i, m and cshow the divis-ions and radia-ting lines of one-half of the fig-\ ure. As the cen-7^ ters may all beframed at theintersections ofthe dotted lines,further explan-ations are un-^ necessary. I close thisdepartment byillustrating a nornament inwhich the…
Architecture · Architectural drawing
