Easy steps in architecture and architectural drawing .. (1915)
Hodgson, Frederick Thomas, 1836- [from old catalog] · Chicago, Ill., Printed by F. J. Drake & co. · leaf 676
s and suggestionsregarding this work. The first thing to do when ARCHITECTURAL DRAWING SELF TAUGHT 247 coloring i s in-tended is to seethat the paperhas all the super-fluous sizing re-moved by beingsponged lightlywith clean water.The paper, andeverythingabout it, mustbe kept perfect-ly clean.… … 248 ARCHITECTURAL DRAWING SELF TAUGHT PLATE 17. This plate shows a basement window in astone wall, the elevation showing the outside ofthe window, and the section exhibits the mannerof constructing the frame and placing the sashes. foot AT?PHTTT?.rTTTT? \T. nRATXJTTOn CTTT-C T A TTrixITi 248…
Architecture · Architectural drawing
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
