of the vaulting. This style has been designated the Tu-dor, Rectilinear Continuous, or Perpendicular style. 62 EASY LESSONS IN ARCHITECTURE Q. What is the shape of the arches in this style? A. Pointed but much depressed (Figs. 71-73). Thisstyle is remarkable for the introduction and use of… … Fig. 61. Q. Describe the window tracery of this period. A. The perpendicular principle of this style isfurther carried out by the extension of the mullions upto the tops of the windows in place of the flowing tra-cery of the preceding style. The immense size of someof the windows necessitated the…
