137 Fig. 131 shows a diagram of the system which cuts any lamp out of the circuit, without affecting the other lamps. X and Y are the two ter- minals of the lamp, II the solenoid for regulating the arc, and T the electro- magnet of the cut-off. This electro-magnet is wound with two wires; one … Kl<i. 128. not shown, is of fine wire placed in the same derived circuit as the fine wire of the solenoid ; the other, short and thick, leading from X to X by B and R, but interrupted at M. \\ hile the current is normal, the cur-
