e galvanometer having been disconnected fromcable in the meantime, take another discharge-reading of cables, and applythe same formula as before. If a condenser of low capacity be inserted be-tween K and the galvanometer, the latter need not be disconnected. Theadvantage of the use of the… … Fig. 3. G is a high-resistance mirror galvanometer. S is the shunt. /., is the short-circuit key. It may he on the shunt hox or separate. K,/ is a reversing key. KN/ is a discharge key. B the hattery, usually 100 cells chloride of silver. C is a I microfarad standard condenser. The joint to he…
