Fin. 23.—Simple Graded Ammeter … Il(}. 24.—Lord Kelvin s Graded \oUmeter accompanying Figs. 24 and 25. The coils of wire are shown fixed tothe end of sliding table; the needles are carried in the sector-shapedboxes, and have a long light pointer swinging over a scale, ihesliding table has a scale for multiplying the readings of…
