st observed by sliding the wirealonof until the needle isat zero, and then, bytapping the wires to-gether, noting whetherthe needle moves to oneside or other ; if it movesto one side or other, tapit a little further alonguntil a spot is touchedwhere the needle doesnot move: the doublescale can then… … Fig. 31.—Section of Scale of Metre Bridge Resistance Coils required. The pressure gauge is used as a galvanometer when theneedle is in or near centre of the coil, and is to be used with thisbridge for measurements. A standard i ohm resistance will be required. This can bebought for three or four…
