Fig. 30. Figs. 35 and 36 show forms which have trans-parent dials illuminated from behind. Instruments of this pattern are often mountedon a swinging arm that they may be read fromvarious parts of the room. A black disc controlled by a button in the middleof the case front, is set to a determined… … VOLTMETERS AND AMMETERS. 45 The pointer is then more readily located as to itsproximity to this disc when viewed from a distance. Sensibility. In the Weston direct current in-struments of the portable or the Type B form, aresistance of about 100 ohms per volt is added. In the other types of…
