e connections to shunts must be VOLTMETERS AXD AMMETERS. 59 as perfect as possible. Poor contact causes heat-ing if at the bus-bar connections and thereby in-correct indicating at the instrument terminals. The shunt cords must also be properly clampedcr incorrect readings will result. The… … Fig. 45. bind the looped part if desired with tape. Ashortened cord would increase reading of instru-ments as it lowers the resistance in series with theammeter. And a poor connection would decreasereadings on account of its resistance. Too little attention is often given to these pointsby those in…
