each particular case. LOIVG-RANGE MAGNEXS. 2436. The most economical form of long-range mag-nets is the coil-and-plunger magnet; that is, a magnetin which a part or the whole of the armature moves insidethe magnetizing coils. The simplest, although the most in-efficient, type of such magnets is a… … The range of action is long, but the force exerted is comparatively weak. Fig. 964 represents an effective type of coil-and-plunger 1578 PRINCIPLES OF magnet, and one capable of exerting heavy pulls throughlong ranges. The magnetic circuit is divided at about thecenter of the coils c, c, and half…
