from the edge of the jar. The copper (7 is a flat strip bentinto a circle, which rests on the bottom of the jar. Con- BATTERIES. 1735 nectlon ■ is made between itmeans of a wire JV,which is insulatedwith some rubbercompound where itpasses through theliquids. The posi-tion of the twoliquids is shown…
