y the shorttube S. In the bottom of the tubesare the elements P and tV, towhich connection is made bymeans of the wires W, IV, whichare sealed into the glass. Thesewires are led to binding-postsconveniently mounted on thecase. The space above the ele-ments is filled with the electro-lyte, and the… … 1750 BATTERIES. piece of cloth F, with a perforated cork M laid over it.When this is forced down the tube to the surface of theelement, the cloth keeps the element in place, and the corkholds the cloth, the perforations allowing free access of theliquid to the elements. This is the general form in…
