International Library of Technology · Scranton, International Textbook Co. · leaf 460
«,which is on the diameter about at right angles to the planeof the coil, and at a sufficient radial distance from the axisof the core to clear the shaft. At this point the conductoris bent outward at right angles, carried along away from 1992 APPLIED ELECTRICITY. the core parallel to the shaft for… … next coil c d, which is located two winding spaces awayfrom coil a b (see Art. 3137), a similar process is gonethrough with, the two spiral connectors being carried alongparallel with those of the first coil to be wound, as repre-sented. 3152. It will be seen that by completing the wholewinding in…
Electrical engineering
Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
![An illustration from [Electric engineering.], 1902, leaf 460](https://img.insideoutlibrary.com/img/1024/ia-electricengineer01inte-460-182.webp)
