hin reasonable limits. The application of the principle of multiple windingsto the various types of armature windings will now betaken up. MULTIPLE-WOUND MULTIPLE-CIRCUIT RING WINDINGS. 3170. The multiple-circuit winding is the simplestform of ring winding, and, as has already been pointedout, it… … Fig. 1177. coils of each winding are supposed to lie between successivecoils of the others, it follows that, in connecting up the coilsof a ring winding to form vi separate windings, each coil isconnected to the inth. coil on each side; that is, in — 1 coilsare skipped over in connecting successive…
