ecoils, 2 — 1 = 1 coil is skipped once, and alternate coils areconnected in each winding. Coils numbered i, 2, S, etc.,represent the one winding, and coils 1\ 2\S\ etc., representthe other. 3171. It will be seen that, in connecting alternate coilsof the even number (36) which is used in this case,… … Fig. 1178. This results from the fact that the total number of coilsis divisible by the number of windings, without a remainder. If the number of coils is so chosen that there is a remain-der, then, after passing through alternate coils once aroundthe armature, the end of the last coil connected…
Electrical engineering
