International Library of Technology · Scranton, International Textbook Co. · leaf 490
2022 APPLIED ELECTRICITY. made in this country use this type of magnets with the coilhorizontal and below the armature. Further, the armatureshaft may either have the direction indicated or be at rightangles to that direction, if desired, without changing thecharacter of the field-magnet. The… … 3194. A form of consequent-pole field-magnet which isderived from that just described is shown in Fig. 1184. This form of field-mag- net is known as the Manchester type, andis used by the MatherElectric Co., the West-inghouse Co., and othersin this country. This is practically thesame form of…
Electrical engineering
Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
![An illustration from [Electric engineering.], 1902, leaf 490](https://img.insideoutlibrary.com/img/1024/ia-electricengineer01inte-490-194.webp)
