International Library of Technology · Scranton, International Textbook Co. · leaf 492
net yoke in Fig. 1183(J/and J/), a type of field-magnet results which iscommonly known as thehorseshoe type, as illus-trated in Fig. 1186. It willbe seen that in these twoforms the magnet yoke (M)of each corresponds to thefield core of the other. ThisFig. 1186. type of field-magnet is very… … APPLIED ELECTRICITY. 2025 The General Electric Co. in their Edison machines, theCommercial Electric Co., the Eddy Electric ManufacturingCo., and others, use the same form of magnet in the reverseposition, i. e., with the magnet frame above the armature. The Excelsior arc machine employs the same…
Electrical engineering
Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
![An illustration from [Electric engineering.], 1902, leaf 492](https://img.insideoutlibrary.com/img/1024/ia-electricengineer01inte-492-196.webp)
