International Library of Technology · Scranton, International Textbook Co. · leaf 60
IAL. 2312. Referring again to the flow of water in pipes,we may tabulate the analogies as given in Table 77, a care-ful study of which will do much to assist the understandingof what is to follow. 2313. The fourth analogy of the table states thatthe loss of pressure or E. M. F., due to the… … , Fig. 913. vertical tubes at a, b, c, etc. If the outlet at N is closedthe water in the vertical tubes will rise to the height of thewater in the tank ; but if the water is allowed to flow freelyfrom the outlet at N, then the height of the water in thetubes will be represented by the inclined line…
Electrical engineering
Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
![An illustration from [Electric engineering.], 1902, leaf 60](https://img.insideoutlibrary.com/img/1024/ia-electricengineer01inte-60-8.webp)
