International Library of Technology · Scranton, International Textbook Co. · leaf 89
is one composed of some magneticsubstance having a uniform sectionalFig. 925. area throughout its entire length, as shown in Fig, 925, which represents a simple ring. ELECTRICITY AND MAGNETISM. 1523 2372. A compound magnetic circuit is a circuit inwhich the lines of force pass consecutively through… … 2373. A closed magneticcircuit is a circuit composed en-tirely of magnetic substances, andin which the lines of force do not ^-^°- ^^^■ pass across an air-gap, A c/oscd magnetic circuit may some-times .be a compound one, as would be the case, for instance,in Fig. 926 if the air-gaps there shown…
Electrical engineering
Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
![An illustration from [Electric engineering.], 1902, leaf 89](https://img.insideoutlibrary.com/img/1024/ia-electricengineer01inte-89-18.webp)
