International Library of Technology · Scranton, International Textbook Co. · leaf 154
Fig. 41. wires. Then connect as shown in Fig. 41 and measure theresistance from D to B through the cross F. Let the/. III.—10 38 ELECTRIC TRANSMISSION. 15 resistance of the cross be z ohms and the resistance foundby balancing the bridge be R ohms. Then, R = x+y-\-z. (1) Now ground either wire, say…
Electrical engineering
Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
![An illustration from [Electric engineering.], 1902, leaf 154](https://img.insideoutlibrary.com/img/1024/ia-electricengineer03inte-154-93.webp)
