und machine, becausethe latter will maintain the line voltage with an increase ofload; whereas, with shunt-wound machines, the line voltagewill fall off, unless the switchboard attendant cuts out somefield resistance. COMPOUND-WOUND MACHINES IN PARALLEL,. 83. Since the compound-wound machine is a… … M ^_-ifl==^ Bus Bar + r~/e/d Sw/fcft Fig. 60. connections in their simplest possible form; we have twomachines A and B of equal size and the equalizer E run-ning directly between them; c and/are the -|- terminals of § 15 ELECTRIC TRANSMISSION. 73 the machine, while cda.nd.fe represent the leads, or…
