International Library of Technology · Scranton, International Textbook Co. · leaf 325
(a) … WG Fig 35. only indicates whether a ground is present, but by itsdeflection it shows whether the path of the current toaround is one of hiodi resistance or low resistance. 34 ELECTRIC LIGHTING. § 17 In order to indicate grounds, the voltmeter may be con-nected as shown in Fig. 35 (a); a and b are…
Electrical engineering
Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
![An illustration from [Electric engineering.], 1902, leaf 325](https://img.insideoutlibrary.com/img/1024/ia-electricengineer03inte-325-201.webp)
