International Library of Technology · Scranton, International Textbook Co. · leaf 363
p. m., thus giving an oppor-tunity for inspection or repair and allowing the station to berun with a small force of men. When the generators arestarted up at 2 p. m., the batteries are charged, as shown bythe single-shaded area, thus allowing the generators in useto be run at more nearly their… … Fig. central station and C one of the substations. The three-wire system is here shown, as this is the one most largelyused in distribution of this kind. The network of lamps fedfrom the substation C is represented by D. Now the loadof lamps represented by D may be much in excess of what 72…
Electrical engineering
Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
![An illustration from [Electric engineering.], 1902, leaf 363](https://img.insideoutlibrary.com/img/1024/ia-electricengineer03inte-363-229.webp)
