International Library of Technology · Scranton, International Textbook Co. · leaf 533
Fig. 4. Figs. 5 and 6 show burn-outs caused by short circuits incut-outs. The burn-outin Fig. 5 was due to de-fective design, the twosides of the circuit beingbrought so close togetherthat when a fuse meltedthe arc held over and de-stroyed the cut-out. In Fig. 6, the cut-outwas placed horizontally.…
Electrical engineering
Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
![An illustration from [Electric engineering.], 1902, leaf 533](https://img.insideoutlibrary.com/img/1024/ia-electricengineer03inte-533-329.webp)
