ed, showingthe magnet coils m, m! and the armature a. An adjustingscrew s is provided to regulate the stroke of the armatureand the consequent intensity of sound. The wires from thepush button and battery are secured at d and e, and on clo-sing the circuit, the rapid vibration of the armature… … Fig. C. 34. The circuit-closing devices used on bellwork usuallytake the form of a push, button. These are made in all sorts of styles. The very cheapones are seldom satisfactory.Bronze push buttons should beused where exposed to theweather. Fig. 7 shows the or-dinary round push button. Thewires…
