branch-offto the horizontal straight track and a left-hand branch-offto the vertical one. Fig. 52 {e) is what is known as aplain Y. Fig. 52 (/) is a three-part Y and Fig. 52 {g) athrough Y. The three-part Y can be used instead of a loopto turn single-end cars at the end of the line. Fig. 52 (//) 32… … Fig. 53. cross over from one track to the other. These are veryconvenient devices to place here and there in a main Hne toturn cars back, either when they are crippled or to get them 50 ELECTRIC RAILWAYS. § 22 on their time after a long delay. When it is practicable, across-over should be put in so…
